Raimondi Follows Tower-Crane Introduction with Luffing Crane

565

Italian-made Raimondi Cranes SpA, has added to its luffing-crane lineup with the Model LR213. The luffer was designed for the urban jobsite involving high-rise buildings in close proximity or areas with difficult-to-obtain flyover rights. With five pre-launch orders, deliveries of the new crane have begun from the manufacturer’s headquarters in Italy.

According to the manufacturer, the LR213’s standout features include hoisting performance, flexibility, and easy maintenance. The luffing crane can lift the maximum load with the full jib of 55 meters. This not only increases loading capacity, but also increases speed and additional rope capacity. Two hoisting winches, at 55 kW or 75 kW, are available.

The crane is a result of solution-based design. It is easy to maintain, with hoisting and luffing winches mounted on a big counterjib platform. An increased counterjib surface is a result of the two lateral big service platforms. All the safety mechanisms and electronic devices are located on the counterjib, offering easy access for technicians and operators. The LR213 has the capacity to carry 1,000 meters of rope on its drum, allowing for a lifting capacity of 14 tonnes in four falls at a working height of 250 meters.

The largest luffing crane in the Raimondi range, the LR213 is available with five different jib length configurations, from a maximum jib length of 55 meters to a minimum jib length of 28 meters, that can all reach the maximum capacity of 14,000 kg. The max tip load with 55 meter jib configuration is 2,250 kg. Only one electrical cabinet installed on the cabin platform facilitates quick installation and cable connection. The crane is equipped with Raimondi’s new Deluxe R16 crane cabin.

The launch of Raimondi’s latest luffing crane comes on the heels of the unveiling of the MRT159 tower crane, with a 65-meter jib length and a maximum tip load of 1,650 kg. Deliveries of the tower crane, which boasts a maximum load of 10,000 kg, began this month.
